Millions of patterns have already been created using the VIOSO Test Pattern Generator. Now we have completely redesigned it, adding new tools for projection professionals working across everything from flat surfaces and LED walls to immersive domes and simulation environments.

The new cloud-based generator creates traditional pixel-based test patterns as well as precision metric grids. This makes it possible to project real-world measurements directly onto floors, walls and other physical surfaces, helping with alignment, installation planning and geometry checks.

The biggest addition is support for fully configurable Domemaster test patterns. Choose a standard resolution from 1K to 8K or enter your own custom resolution, then adjust the grid spacing and line angles, add compass overlays for orientation and include your own company branding.

The Test Pattern Generator is now part of the VIOSO Cloud Platform alongside VIOSO Experience Designer. It can be used free in a browser without an account, while registered users can also save projects, organise their patterns and share them with colleagues.

Whether you are checking projector alignment, verifying content orientation, commissioning an LED wall or preparing a dome installation, the right reference pattern is now only a few clicks away.
